Home   ·   About   ·   Tipi   ·   Yurt / Ger   ·   Dome   ·   Features   ·   Gallery About Overview License Tipi Overview Tipi Diary Yurt / Ger Overview Yurt Notes & Calculator Yurt / Ger Diary Yurt Builder Conference Living Notes Material Notes Dome Overview Geodesic Dome Geodesic Dome Notes & Calculator Geodesic Dome Diary Geodesic Polyhedra Polyhedra Notes Bow Dome Triangulated Bow Dome Star Dome Star Dome Diary Wigwam Zome Helix Zome Low Cost Dome (PVC) Miscellaneous Domes Features Overview Chris Aeppli Claudius Kern René K. Müller Geodesic Solitude Johnny's Capsule Geodesic Clay Mud Dome Jurtendorf (Switzerland) Neolithics of Pfyn Strawbale Cabin Dome Geodesic Dome Geodesic Dome Notes & Calculator Table of Content Introduction Overview of Variants How to Use the Notes Strut Options & Notion The Icosahedron The Octahedron The Cube The Cuboctahedron The Truncated Octahedron The Rhombicuboctahedron Building Models Real Life Application Links Geodesic Dome Diary Geodesic Polyhedra Polyhedra Notes Bow Dome Triangulated Bow Dome Star Dome Star Dome Diary Wigwam Zome Helix Zome Low Cost Dome (PVC) Miscellaneous Domes Site Search Enter term & press ENTER If you found the information useful, consider to make a donation:   Page << Prev | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 | 15 | 16 | 17 | 18 | 19 | Next >> Geodesic Dome Notes & Calculator written by Rene K. Mueller, Copyright (c) 2005, 2006, 2007, last updated Tue, January 29, 2019 4V Octahedron Dome Geodesic 4V Octahedron Dome (front view) Geodesic 4V Octahedron Dome (bird view) vertices/connectors: 41 4 x 3-way 13 x 4-way 24 x 6-way 4V Octahedron Dome Construction Map edges/struts & bending angles (αstrut): A x 16: 0.32036 (9.22°) B x 24: 0.43887 (12.68°) C x 12: 0.44721 (12.92°) D x 16: 0.45951 (13.28°) E x 24: 0.51764 (15.00°) F x 12: 0.57735 (16.78°) total 104 struts (6 kinds)1) strut variance 80.2% faces: 64 (3-sided) A-A-C x 12 (45.74°, 45.74°, 88.51°) B-B-C x 12 (59.37°, 59.37°, 61.26°) B-D-E x 24 (52.98°, 56.71°, 70.32°) E-E-F x 12 (56.10°, 56.10°, 67.80°) F-F-F x 4 (60.00°, 60.00°, 60.00°) 5 kinds of faces2) diameter: 2.000, radius: 1.000 height: 1.000 or 50.00% of diameter 1) strut lengths sorted by 1/10'000th or +/-0.00005 exact 2) clock wise (cw) and counter clock wise (ccw) orientation neglected 4V Octahedron Dome Calculator Geodesic 4V Octahedron Dome (Human is 170cm/5'7") d = , lhole = (Edit numbers & hit TAB to recalculate) Alath = x 16, Blath = x 24, Clath = x 12, Dlath = x 16, Elath = x 24, Flath = x 12, h = L3 Octahedron Dome Geodesic L3 Octahedron Dome (front view) Geodesic L3 Octahedron Dome (bird view) vertices/connectors: 41 4 x 3-way 13 x 4-way 24 x 6-way L3 Octahedron Dome Construction Map edges/struts & bending angles (αstrut): A x 32: 0.39018 (11.25°) B x 24: 0.42291 (12.21°) C x 24: 0.51764 (15.00°) D x 12: 0.54120 (15.70°) E x 12: 0.57735 (16.78°) total 104 struts (5 kinds)1) strut variance 48.0% faces: 64 (3-sided) A-A-D x 12 (46.09°, 46.09°, 87.81°) A-B-C x 24 (47.72°, 53.31°, 78.96°) B-B-D x 12 (50.22°, 50.22°, 79.56°) C-C-E x 12 (56.10°, 56.10°, 67.80°) E-E-E x 4 (60.00°, 60.00°, 60.00°) 5 kinds of faces2) diameter: 2.000, radius: 1.000 height: 1.000 or 50.00% of diameter 1) strut lengths sorted by 1/10'000th or +/-0.00005 exact 2) clock wise (cw) and counter clock wise (ccw) orientation neglected L3 Octahedron Dome Calculator Geodesic L3 Octahedron Dome (Human is 170cm/5'7") d = , lhole = (Edit numbers & hit TAB to recalculate) Alath = x 32, Blath = x 24, Clath = x 24, Dlath = x 12, Elath = x 12, h = The nice thing is here, that the L3 provides at 3/8 and 5/8 also an almost even base line. L3 1/4 Octahedron Dome Geodesic L3 3/8 Octahedron Dome (front view) Geodesic L3 3/8 Octahedron Dome (bird view) vertices/connectors: 25 4 x 3-way 9 x 4-way 12 x 6-way L3 3/8 Octahedron Dome Construction Map edges/struts & bending angles (αstrut): A x 12: 0.39018 (11.25°) B x 16: 0.42291 (12.21°) C x 16: 0.51764 (15.00°) D x 4: 0.54120 (15.70°) E x 12: 0.57735 (16.78°) total 60 struts (5 kinds)1) strut variance 48.0% faces: 36 (3-sided) A-A-D x 4 (46.09°, 46.09°, 87.81°) A-B-C x 16 (47.72°, 53.31°, 78.96°) B-B-D x 4 (50.22°, 50.22°, 79.56°) C-C-E x 8 (56.10°, 56.10°, 67.80°) E-E-E x 4 (60.00°, 60.00°, 60.00°) 5 kinds of faces2) diameter: 2.000, radius: 1.000 height: 0.617 or 30.87% of diameter 1) strut lengths sorted by 1/10'000th or +/-0.00005 exact 2) clock wise (cw) and counter clock wise (ccw) orientation neglected L3 3/8 Octahedron Dome Calculator Geodesic L3 3/8 Octahedron Dome (Human is 170cm/5'7") d = , lhole = (Edit numbers & hit TAB to recalculate) Alath = x 12, Blath = x 16, Clath = x 16, Dlath = x 4, Elath = x 12, h = Here again uneven base, for heavy construction leveling necessary. L3 5/8 Octahedron Dome Geodesic L3 5/8 Octahedron Dome (front view) Geodesic L3 5/8 Octahedron Dome (bird view) vertices/connectors: 53 13 x 4-way 4 x 5-way 36 x 6-way L3 5/8 Octahedron Dome Construction Map edges/struts & bending angles (αstrut): A x 36: 0.39018 (11.25°) B x 40: 0.42291 (12.21°) C x 32: 0.51764 (15.00°) D x 20: 0.54120 (15.70°) E x 16: 0.57735 (16.78°) total 144 struts (5 kinds)1) strut variance 48.0% faces: 92 (3-sided) A-A-D x 20 (46.09°, 46.09°, 87.81°) A-B-C x 32 (47.72°, 53.31°, 78.96°) B-B-D x 20 (50.22°, 50.22°, 79.56°) C-C-E x 16 (56.10°, 56.10°, 67.80°) E-E-E x 4 (60.00°, 60.00°, 60.00°) 5 kinds of faces2) diameter: 2.000, radius: 1.000 height: 1.408 or 70.41% of diameter 1) strut lengths sorted by 1/10'000th or +/-0.00005 exact 2) clock wise (cw) and counter clock wise (ccw) orientation neglected L3 5/8 Octahedron Dome Calculator Geodesic L3 5/8 Octahedron Dome (Human is 170cm/5'7") d = , lhole = (Edit numbers & hit TAB to recalculate) Alath = x 36, Blath = x 40, Clath = x 32, Dlath = x 20, Elath = x 16, h = Here again uneven base, for heavy construction leveling necessary. Next Page >> Page << Prev | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 | 15 | 16 | 17 | 18 | 19 | Next >> Content: Page 1: Table of Content, Changes Page 2: Introduction, Origin of the Geodesic Dome, Geodesize: Triangulate & Normalize, Procedure & Evolution of a Subdividing Triangle ... Page 3: Overview of Variants, Numerical Overview, Amount of Struts vs. Strut Variance, Amount of Struts vs. Strut Types ... Page 4: The Icosahedron, 1V/L1 2/3 Icosahedron Dome, 2V/L2 Icosahedron Dome, 3V 4/9 Icosahedron Dome ... Page 5: 5V 7/15 Icosahedron Dome, 5V 8/15 Icosahedron Dome, 6V Icosahedron Dome, 2V.3V Icosahedron Dome ... Page 6: 7V 10/21 Icosahedron Dome, 7V 11/21 Icosahedron Dome, 8V Icosahedron Dome, L4 Icosahedron Dome ... Page 7: The Octahedron, 1V/L1 Octahedron Dome, 2V/L2 Octahedron Dome, 3V Octahedron Dome Page 8: 4V Octahedron Dome, L3 Octahedron Dome, L3 1/4 Octahedron Dome, L3 5/8 Octahedron Dome Page 9: 5V Octahedron Dome, 6V Octahedron Dome, 2V.3V Octahedron Dome, 3V.2V Octahedron Dome Page 10: 7V Octahedron Dome, 8V Octahedron Dome, L4 Octahedron Dome, L4 7/16 Octahedron Dome, L4 9/16 Octahedron Dome ... Page 11: 9V Octahedron Dome, 3V.3V Octahedron Dome, 10V Octahedron Dome, 2V.5V Octahedron Dome, 2V.5V Octahedron Dome ... Page 12: The Cube, Preparing the Cube, 1V/L1 Cube Dome, 2V/L2 Cube Dome, 3V Cube Dome, 4V Cube Dome, L3 Cube Dome ... Page 13: 5V Cube Dome, 6V Cube Dome, 2V.3V Cube Dome, 3V.2V Cube Dome, 7V Cube Dome Page 14: The Cuboctahedron, Preparing the Cuboctahedron, 1V/L1 Cuboctahedron Dome, 2V/L2 Cuboctahedron Dome ... Page 15: 5V Cuboctahedron Dome, 6V Cuboctahedron Dome, 2V.3V Cuboctahedron Dome, 3V.2V Cuboctahedron Dome ... Page 16: The Truncated Octahedron, Preparing the Truncated Octahedron, 1V/L1 Truncated Octahedron Dome ... Page 17: The Rhombicuboctahedron, Preparing the Rhombicuboctahedron, 1V/L1 3/8 Rhombicuboctahedron Dome ... Page 18: Building Models, 3V 5/9 Icosahedron Model, 2V Icosahedron Model, 4V Icosahedron Model, 2V/L2 Cuboctahedron Model ... Page 19: Real Life Application, Options, Connectors, Separate Functions, Cover, 4/8 Sphere Cover Calculator ... Home   ·   About   ·   Tipi   ·   Yurt   ·   Dome   ·   Features   ·   Gallery Print   ·   Bookmark Creative Commons (CC) BY-SA-NC 2005-2017, developed, designed and written by René K. Müller Graphics & illustrations made with Inkscape, Tgif, Gimp, PovRay, GD.pm Web-Site powered by FreeBSD & Debian/Linux - 100% Open Source
