Home   ·   About   ·   Tipi   ·   Yurt / Ger   ·   Dome   ·   Features   ·   Gallery About Overview License Tipi Overview Tipi Diary Yurt / Ger Overview Yurt Notes & Calculator Yurt / Ger Diary Yurt Builder Conference Living Notes Material Notes Dome Overview Geodesic Dome Geodesic Dome Notes & Calculator Geodesic Dome Diary Geodesic Polyhedra Polyhedra Notes Bow Dome Triangulated Bow Dome Star Dome Star Dome Diary Wigwam Zome Helix Zome Low Cost Dome (PVC) Miscellaneous Domes Features Overview Chris Aeppli Claudius Kern René K. Müller Geodesic Solitude Johnny's Capsule Geodesic Clay Mud Dome Jurtendorf (Switzerland) Neolithics of Pfyn Strawbale Cabin Dome Geodesic Dome Geodesic Dome Notes & Calculator Table of Content Introduction Overview of Variants How to Use the Notes Strut Options & Notion The Icosahedron The Octahedron The Cube The Cuboctahedron The Truncated Octahedron The Rhombicuboctahedron Building Models Real Life Application Links Geodesic Dome Diary Geodesic Polyhedra Polyhedra Notes Bow Dome Triangulated Bow Dome Star Dome Star Dome Diary Wigwam Zome Helix Zome Low Cost Dome (PVC) Miscellaneous Domes Site Search Enter term & press ENTER If you found the information useful, consider to make a donation:   Page << Prev | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 | 15 | 16 | 17 | 18 | 19 | Next >> Geodesic Dome Notes & Calculator written by Rene K. Mueller, Copyright (c) 2005, 2006, 2007, last updated Tue, January 29, 2019 9V Octahedron Dome Geodesic 9V Octahedron Dome (front view) Geodesic 9V Octahedron Dome (bird view) vertices/connectors: 181 4 x 3-way 33 x 4-way 144 x 6-way 9V Octahedron Dome Construction Map edges/struts & bending angles (αstrut): A x 16: 0.12427 (3.56°) B x 24: 0.14146 (4.06°) C x 16: 0.15379 (4.41°) D x 24: 0.16250 (4.66°) E x 12: 0.17541 (5.03°) F x 24: 0.17837 (5.12°) G x 16: 0.18508 (5.31°) H x 24: 0.18597 (5.34°) I x 24: 0.19519 (5.60°) J x 48: 0.20635 (5.92°) K x 40: 0.21070 (6.05°) L x 48: 0.21572 (6.19°) M x 20: 0.22086 (6.34°) N x 24: 0.23223 (6.67°) O x 48: 0.24080 (6.92°) P x 48: 0.24592 (7.06°) Q x 24: 0.26261 (7.55°) R x 24: 0.26495 (7.61°) total 504 struts (18 kinds)1) strut variance 113.2% faces: 324 (3-sided) A-A-E x 12 (45.13°, 45.13°, 89.75°) B-B-E x 12 (51.70°, 51.70°, 76.60°) B-C-I x 24 (45.97°, 51.39°, 82.64°) D-F-I x 24 (51.32°, 58.99°, 69.68°) D-G-K x 24 (47.94°, 57.75°, 74.30°) F-F-M x 12 (51.75°, 51.75°, 76.50°) H-K-L x 48 (51.71°, 62.76°, 65.53°) J-J-M x 24 (57.65°, 57.65°, 64.70°) J-L-O x 48 (53.42°, 57.05°, 69.53°) N-O-P x 48 (56.98°, 60.40°, 62.62°) P-P-Q x 24 (57.73°, 57.73°, 64.55°) Q-R-R x 24 (59.40°, 60.30°, 60.30°) 12 kinds of faces2) diameter: 2.000, radius: 1.000 height: 1.000 or 50.00% of diameter 1) strut lengths sorted by 1/10'000th or +/-0.00005 exact 2) clock wise (cw) and counter clock wise (ccw) orientation neglected 9V Octahedron Dome Calculator Geodesic 9V Octahedron Dome (Human is 170cm/5'7") d = , lhole = (Edit numbers & hit TAB to recalculate) Alath = x 16, Blath = x 24, Clath = x 16, Dlath = x 24, Elath = x 12, Flath = x 24, Glath = x 16, Hlath = x 24, Ilath = x 24, Jlath = x 48, Klath = x 40, Llath = x 48, Mlath = x 20, Nlath = x 24, Olath = x 48, Plath = x 48, Qlath = x 24, Rlath = x 24, h = 3V.3V Octahedron Dome Geodesic 3V.3V Octahedron Dome (front view) Geodesic 3V.3V Octahedron Dome (bird view) vertices/connectors: 181 4 x 3-way 33 x 4-way 144 x 6-way 3V.3V Octahedron Dome Construction Map edges/struts & bending angles (αstrut): A x 32: 0.15315 (4.39°) B x 16: 0.15689 (4.50°) C x 24: 0.15697 (4.50°) D x 24: 0.15706 (4.50°) E x 24: 0.16057 (4.60°) F x 40: 0.21070 (6.05°) G x 12: 0.21595 (6.20°) H x 24: 0.21723 (6.24°) I x 20: 0.22086 (6.34°) J x 24: 0.22224 (6.38°) K x 96: 0.22365 (6.42°) L x 48: 0.23512 (6.75°) M x 24: 0.23594 (6.77°) N x 48: 0.23610 (6.78°) O x 48: 0.23760 (6.82°) total 504 struts (15 kinds)1) strut variance 55.1% faces: 324 (3-sided) A-A-G x 12 (45.17°, 45.17°, 89.65°) A-D-F x 24 (46.46°, 48.02°, 85.52°) B-C-H x 24 (46.20°, 46.24°, 87.57°) C-C-G x 12 (46.54°, 46.54°, 86.93°) D-E-H x 24 (46.20°, 47.55°, 86.25°) E-E-I x 12 (46.55°, 46.55°, 86.90°) F-K-L x 48 (54.62°, 59.91°, 65.47°) I-N-N x 24 (55.78°, 62.11°, 62.11°) J-K-K x 24 (59.59°, 60.21°, 60.21°) J-O-O x 24 (55.76°, 62.12°, 62.12°) K-L-N x 48 (56.66°, 61.45°, 61.90°) K-M-O x 48 (56.36°, 61.44°, 62.21°) 12 kinds of faces2) diameter: 2.000, radius: 1.000 height: 1.000 or 50.00% of diameter 1) strut lengths sorted by 1/10'000th or +/-0.00005 exact 2) clock wise (cw) and counter clock wise (ccw) orientation neglected 3V.3V Octahedron Dome Calculator Geodesic 3V.3V Octahedron Dome (Human is 170cm/5'7") d = , lhole = (Edit numbers & hit TAB to recalculate) Alath = x 32, Blath = x 16, Clath = x 24, Dlath = x 24, Elath = x 24, Flath = x 40, Glath = x 12, Hlath = x 24, Ilath = x 20, Jlath = x 24, Klath = x 96, Llath = x 48, Mlath = x 24, Nlath = x 48, Olath = x 48, h = 10V Octahedron Dome Geodesic 10V Octahedron Dome (front view) Geodesic 10V Octahedron Dome (bird view) vertices/connectors: 221 4 x 3-way 37 x 4-way 180 x 6-way 10V Octahedron Dome Construction Map edges/struts & bending angles (αstrut): A x 16: 0.11060 (3.17°) B x 24: 0.12408 (3.56°) C x 16: 0.13422 (3.85°) D x 24: 0.14037 (4.02°) E x 24: 0.15305 (4.39°) F x 12: 0.15617 (4.48°) G x 24: 0.15897 (4.56°) H x 16: 0.15974 (4.58°) I x 24: 0.17214 (4.94°) J x 24: 0.17475 (5.01°) K x 24: 0.17715 (5.08°) L x 16: 0.18286 (5.25°) M x 24: 0.18357 (5.27°) N x 24: 0.18563 (5.33°) O x 24: 0.18984 (5.45°) P x 12: 0.19245 (5.52°) Q x 24: 0.19270 (5.53°) R x 24: 0.19673 (5.65°) S x 16: 0.19708 (5.66°) T x 24: 0.20840 (5.98°) U x 24: 0.20865 (5.99°) V x 24: 0.20967 (6.02°) W x 24: 0.21329 (6.12°) X x 24: 0.21808 (6.26°) Y x 12: 0.21822 (6.26°) Z x 24: 0.22923 (6.58°) AA x 12: 0.22942 (6.59°) AB x 24: 0.23096 (6.63°) AC x 24: 0.23738 (6.82°) AD x 12: 0.24254 (6.97°) total 620 struts (30 kinds)1) strut variance 119.3% faces: 400 (3-sided) A-A-F x 12 (45.08°, 45.08°, 89.84°) AA-U-U x 12 (66.68°, 56.66°, 56.66°) AA-Z-Z x 12 (60.06°, 59.97°, 59.97°) AB-AC-Z x 24 (59.32°, 62.11°, 58.57°) AB-W-X x 24 (64.74°, 56.62°, 58.64°) AC-AC-AD x 12 (59.29°, 59.29°, 61.43°) AD-AD-AD x 4 (60.00°, 60.00°, 60.00°) B-B-F x 12 (51.00°, 51.00°, 78.00°) B-C-I x 24 (45.76°, 50.78°, 83.46°) D-E-I x 24 (50.76°, 57.56°, 71.68°) D-H-N x 24 (47.25°, 56.64°, 76.11°) E-E-P x 12 (51.02°, 51.02°, 77.97°) G-L-Q x 24 (50.01°, 61.80°, 68.20°) G-M-N x 24 (51.02°, 63.84°, 65.14°) J-J-P x 12 (56.57°, 56.57°, 66.86°) J-M-V x 24 (52.23°, 56.18°, 71.59°) K-O-S x 24 (54.48°, 60.66°, 64.86°) K-Q-T x 24 (52.26°, 59.31°, 68.43°) O-O-Y x 12 (54.91°, 54.91°, 70.17°) R-T-X x 24 (54.87°, 60.06°, 65.07°) R-U-V x 24 (56.08°, 61.70°, 62.22°) W-W-Y x 12 (59.24°, 59.24°, 61.53°) 22 kinds of faces2) diameter: 2.000, radius: 1.000 height: 1.000 or 50.00% of diameter 1) strut lengths sorted by 1/10'000th or +/-0.00005 exact 2) clock wise (cw) and counter clock wise (ccw) orientation neglected 10V Octahedron Dome Calculator Geodesic 10V Octahedron Dome (Human is 170cm/5'7") d = , lhole = (Edit numbers & hit TAB to recalculate) Alath = x 16, Blath = x 24, Clath = x 16, Dlath = x 24, Elath = x 24, Flath = x 12, Glath = x 24, Hlath = x 16, Ilath = x 24, Jlath = x 24, Klath = x 24, Llath = x 16, Mlath = x 24, Nlath = x 24, Olath = x 24, Plath = x 12, Qlath = x 24, Rlath = x 24, Slath = x 16, Tlath = x 24, Ulath = x 24, Vlath = x 24, Wlath = x 24, Xlath = x 24, Ylath = x 12, Zlath = x 24, AAlath = x 12, ABlath = x 24, AClath = x 24, ADlath = x 12, h = 2V.5V Octahedron Dome Geodesic 2V.5V Octahedron Dome (front view) Geodesic 2V.5V Octahedron Dome (bird view) vertices/connectors: 221 4 x 3-way 37 x 4-way 180 x 6-way 2V.5V Octahedron Dome Construction Map edges/struts & bending angles (αstrut): A x 32: 0.14897 (4.27°) B x 24: 0.15701 (4.50°) C x 24: 0.15942 (4.57°) D x 32: 0.16077 (4.61°) E x 24: 0.16200 (4.65°) F x 24: 0.16287 (4.67°) G x 16: 0.16512 (4.74°) H x 24: 0.16655 (4.78°) I x 24: 0.16939 (4.86°) J x 24: 0.17295 (4.96°) K x 24: 0.17327 (4.97°) L x 24: 0.17393 (4.99°) M x 24: 0.17615 (5.05°) N x 24: 0.18984 (5.45°) O x 24: 0.20577 (5.91°) P x 12: 0.21009 (6.03°) Q x 24: 0.21329 (6.12°) R x 24: 0.21561 (6.19°) S x 24: 0.21702 (6.23°) T x 24: 0.21808 (6.26°) U x 12: 0.21822 (6.26°) V x 12: 0.22654 (6.50°) W x 24: 0.22702 (6.52°) X x 24: 0.22923 (6.58°) Y x 12: 0.22942 (6.59°) Z x 24: 0.23096 (6.63°) AA x 24: 0.23738 (6.82°) AB x 12: 0.24254 (6.97°) total 620 struts (28 kinds)1) strut variance 62.8% faces: 400 (3-sided) A-A-P x 12 (45.17°, 45.17°, 89.66°) A-C-N x 24 (49.58°, 54.54°, 75.88°) AA-AA-AB x 12 (59.29°, 59.29°, 61.43°) AA-X-Z x 24 (62.11°, 58.57°, 59.32°) AB-AB-AB x 4 (60.00°, 60.00°, 60.00°) B-B-P x 12 (48.00°, 48.00°, 84.00°) B-D-S x 24 (46.21°, 47.67°, 86.12°) C-H-O x 24 (49.32°, 52.43°, 78.26°) D-F-O x 24 (50.07°, 50.98°, 78.95°) E-G-R x 24 (48.15°, 49.39°, 82.46°) E-I-S x 24 (47.63°, 50.59°, 81.78°) F-J-R x 24 (48.05°, 52.12°, 79.83°) H-K-T x 24 (48.75°, 51.45°, 79.80°) I-I-V x 12 (48.05°, 48.05°, 83.91°) J-L-W x 24 (48.92°, 49.31°, 81.77°) K-M-W x 24 (48.94°, 50.06°, 81.00°) L-L-V x 12 (49.37°, 49.37°, 81.27°) M-M-Y x 12 (49.39°, 49.39°, 81.23°) N-N-U x 12 (54.91°, 54.91°, 70.17°) Q-Q-U x 12 (59.24°, 59.24°, 61.53°) Q-T-Z x 24 (56.62°, 58.64°, 64.74°) X-X-Y x 12 (59.97°, 59.97°, 60.06°) 22 kinds of faces2) diameter: 2.000, radius: 1.000 height: 1.000 or 50.00% of diameter 1) strut lengths sorted by 1/10'000th or +/-0.00005 exact 2) clock wise (cw) and counter clock wise (ccw) orientation neglected 2V.5V Octahedron Dome Calculator Geodesic 2V.5V Octahedron Dome (Human is 170cm/5'7") d = , lhole = (Edit numbers & hit TAB to recalculate) Alath = x 32, Blath = x 24, Clath = x 24, Dlath = x 32, Elath = x 24, Flath = x 24, Glath = x 16, Hlath = x 24, Ilath = x 24, Jlath = x 24, Klath = x 24, Llath = x 24, Mlath = x 24, Nlath = x 24, Olath = x 24, Plath = x 12, Qlath = x 24, Rlath = x 24, Slath = x 24, Tlath = x 24, Ulath = x 12, Vlath = x 12, Wlath = x 24, Xlath = x 24, Ylath = x 12, Zlath = x 24, AAlath = x 24, ABlath = x 12, h = 2V.5V Octahedron Dome Geodesic 5V.2V Octahedron Dome (front view) Geodesic 5V.2V Octahedron Dome (bird view) vertices/connectors: 221 4 x 3-way 37 x 4-way 180 x 6-way 5V.2V Octahedron Dome Construction Map edges/struts & bending angles (αstrut): A x 32: 0.12241 (3.51°) B x 24: 0.12334 (3.54°) C x 48: 0.15757 (4.52°) D x 24: 0.15923 (4.57°) E x 24: 0.15977 (4.58°) F x 32: 0.17130 (4.91°) G x 24: 0.17214 (4.94°) H x 12: 0.17279 (4.96°) I x 24: 0.17332 (4.97°) J x 12: 0.17365 (4.98°) K x 48: 0.19523 (5.60°) L x 16: 0.19708 (5.66°) M x 24: 0.19810 (5.68°) N x 24: 0.19866 (5.70°) O x 12: 0.19993 (5.74°) P x 48: 0.20119 (5.77°) Q x 24: 0.20290 (5.82°) R x 24: 0.20452 (5.87°) S x 48: 0.21981 (6.31°) T x 24: 0.22285 (6.40°) U x 24: 0.22431 (6.44°) V x 24: 0.23738 (6.82°) W x 12: 0.24154 (6.94°) X x 12: 0.24254 (6.97°) total 620 struts (24 kinds)1) strut variance 98.1% faces: 400 (3-sided) A-A-H x 12 (45.10°, 45.10°, 89.80°) A-B-G x 24 (45.32°, 45.75°, 88.93°) B-B-H x 12 (45.51°, 45.51°, 88.97°) C-C-J x 12 (56.58°, 56.58°, 66.84°) C-D-G x 24 (56.65°, 57.54°, 65.81°) C-F-Q x 24 (48.92°, 55.02°, 76.05°) C-I-P x 24 (49.08°, 56.19°, 74.73°) D-D-J x 12 (56.96°, 56.96°, 66.08°) E-F-P x 24 (50.02°, 55.23°, 74.75°) E-I-Q x 24 (49.51°, 55.56°, 74.93°) K-K-O x 12 (59.20°, 59.20°, 61.60°) K-L-M x 24 (59.20°, 60.15°, 60.66°) K-P-T x 24 (54.53°, 57.09°, 68.38°) K-R-S x 24 (54.64°, 58.69°, 66.67°) M-M-O x 12 (59.70°, 59.70°, 60.60°) N-P-S x 24 (56.12°, 57.20°, 66.68°) N-R-T x 24 (55.22°, 57.71°, 67.07°) S-S-W x 12 (56.68°, 56.68°, 66.65°) S-U-V x 24 (56.77°, 58.61°, 64.62°) U-U-W x 12 (57.43°, 57.43°, 65.14°) V-V-X x 12 (59.29°, 59.29°, 61.43°) X-X-X x 4 (60.00°, 60.00°, 60.00°) 22 kinds of faces2) diameter: 2.000, radius: 1.000 height: 1.000 or 50.00% of diameter 1) strut lengths sorted by 1/10'000th or +/-0.00005 exact 2) clock wise (cw) and counter clock wise (ccw) orientation neglected 5V.2V Octahedron Dome Calculator Geodesic 5V.2V Octahedron Dome (Human is 170cm/5'7") d = , lhole = (Edit numbers & hit TAB to recalculate) Alath = x 32, Blath = x 24, Clath = x 48, Dlath = x 24, Elath = x 24, Flath = x 32, Glath = x 24, Hlath = x 12, Ilath = x 24, Jlath = x 12, Klath = x 48, Llath = x 16, Mlath = x 24, Nlath = x 24, Olath = x 12, Plath = x 48, Qlath = x 24, Rlath = x 24, Slath = x 48, Tlath = x 24, Ulath = x 24, Vlath = x 24, Wlath = x 12, Xlath = x 12, h = Next Page >> Page << Prev | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 | 15 | 16 | 17 | 18 | 19 | Next >> Content: Page 1: Table of Content, Changes Page 2: Introduction, Origin of the Geodesic Dome, Geodesize: Triangulate & Normalize, Procedure & Evolution of a Subdividing Triangle ... Page 3: Overview of Variants, Numerical Overview, Amount of Struts vs. Strut Variance, Amount of Struts vs. Strut Types ... Page 4: The Icosahedron, 1V/L1 2/3 Icosahedron Dome, 2V/L2 Icosahedron Dome, 3V 4/9 Icosahedron Dome ... Page 5: 5V 7/15 Icosahedron Dome, 5V 8/15 Icosahedron Dome, 6V Icosahedron Dome, 2V.3V Icosahedron Dome ... Page 6: 7V 10/21 Icosahedron Dome, 7V 11/21 Icosahedron Dome, 8V Icosahedron Dome, L4 Icosahedron Dome ... Page 7: The Octahedron, 1V/L1 Octahedron Dome, 2V/L2 Octahedron Dome, 3V Octahedron Dome Page 8: 4V Octahedron Dome, L3 Octahedron Dome, L3 1/4 Octahedron Dome, L3 5/8 Octahedron Dome Page 9: 5V Octahedron Dome, 6V Octahedron Dome, 2V.3V Octahedron Dome, 3V.2V Octahedron Dome Page 10: 7V Octahedron Dome, 8V Octahedron Dome, L4 Octahedron Dome, L4 7/16 Octahedron Dome, L4 9/16 Octahedron Dome ... Page 11: 9V Octahedron Dome, 3V.3V Octahedron Dome, 10V Octahedron Dome, 2V.5V Octahedron Dome, 2V.5V Octahedron Dome ... Page 12: The Cube, Preparing the Cube, 1V/L1 Cube Dome, 2V/L2 Cube Dome, 3V Cube Dome, 4V Cube Dome, L3 Cube Dome ... Page 13: 5V Cube Dome, 6V Cube Dome, 2V.3V Cube Dome, 3V.2V Cube Dome, 7V Cube Dome Page 14: The Cuboctahedron, Preparing the Cuboctahedron, 1V/L1 Cuboctahedron Dome, 2V/L2 Cuboctahedron Dome ... Page 15: 5V Cuboctahedron Dome, 6V Cuboctahedron Dome, 2V.3V Cuboctahedron Dome, 3V.2V Cuboctahedron Dome ... Page 16: The Truncated Octahedron, Preparing the Truncated Octahedron, 1V/L1 Truncated Octahedron Dome ... Page 17: The Rhombicuboctahedron, Preparing the Rhombicuboctahedron, 1V/L1 3/8 Rhombicuboctahedron Dome ... Page 18: Building Models, 3V 5/9 Icosahedron Model, 2V Icosahedron Model, 4V Icosahedron Model, 2V/L2 Cuboctahedron Model ... Page 19: Real Life Application, Options, Connectors, Separate Functions, Cover, 4/8 Sphere Cover Calculator ... Home   ·   About   ·   Tipi   ·   Yurt   ·   Dome   ·   Features   ·   Gallery Print   ·   Bookmark Creative Commons (CC) BY-SA-NC 2005-2017, developed, designed and written by René K. Müller Graphics & illustrations made with Inkscape, Tgif, Gimp, PovRay, GD.pm Web-Site powered by FreeBSD & Debian/Linux - 100% Open Source
